LED LINEAR LIGHTS

Continuous Linear Profile Architectural Illumination

DILIGHT continuous linear LED channels offer seamless diffuse illumination, custom corner joins, and versatile recessed, surface, or suspended mounting options.

Body

Stretched aluminum housing, anodic oxidation finish, 4mm thickness safety glass extra clear.

Finishing
  • Polyester powder paint coating, electrostatically sprayed and oven sublimated.
  • Corrosion resistant.
  • Standard: grey.
  • Other colors are available upon request.

Screws

Stainless steel screws.

Mounting
  • Horizontal direction free adjustment with bracket.
  • Vertical direction -60° to +60°.
  • Location: Floor, Wall and Ceiling.

Light source

High-power leds on metal-core PCB.

Light distribution
  • Beam angle: 5°,12.5°,20°,30°,60°,15×30°,10x60°,15×60°.
  • Other beam angle are available upon request.

Protection grade

Up to IP67 & IK10.

Color Temperature

Warm White/Neutral White/Cool White/RGB.

Power

From 6W to 108W.

Lumen output

From 390 LM to 7 020 LM.

Luminous efficacy

Up to 65 LM/W.

Voltage
  • 100-240V AC.
  • 24V DC.

Regulation
  • ON/OFFF.
  • DMX512F.

Data may be subject to change at any time without prior notice to the user.
